Titan

Saturn VI

Titan Facts

• Titan is the fifteenth of Saturn's known satellites and the largest:
  • distance from Saturn: 1,221,830 km
  • diameter: 5150 km
  • mass: 1.35e23 kg

• In Greek mythology the Titans were a family of giants, the children of Uranus and Gaea, who sought to rule the heavens but were overthrown and supplanted by the family of Zeus.

• Discovered by Huygens in 1655.

• It was long thought that Titan was the largest satellite in the solar system but recent observations have shown that Titan's atmosphere is so thick that its solid surface is slightly smaller than Ganymede's. Titan is nevertheless larger in diameter than Mercury and larger and more massive than Pluto.

• One of the principal objectives of the Voyager 1 mission was the study of Titan. Voyager 1 came within 4000 km of the surface. We learned more in the few minutes of that encounter than in the previous 300 years.

• And yet our knowledge is frustratingly incomplete. Titan is surrounded by a thick, opaque atmosphere; the surface cannot be seen at all in visible light (picture 8). (The Cassini mission will map Titan's surface with radar as Magellan did at Venus.) All that the Voyager images show is a slight variation in color between the northern and southern hemispheres. Some surface detail is visible in the infrared with HST.

• Titan is similar in bulk properties to Ganymede, Callisto, Triton and (probably) Pluto.

• Titan is about half water ice and half rocky material. It is probably differentiated into several layers with a 3400 km rocky center surrounded by several layers composed of different crystal forms of ice. Its interior may still be hot. Though similar in composition to Rhea and the rest of Saturn's moons, it is denser because it is so large that its gravity compresses its interior.

• Alone of all the satellites in the solar system, Titan has a significant atmosphere. At the surface, its pressure is more than 1.5 bar (50% higher than Earth's). It is composed primarily of molecular nitrogen (as is Earth's) with no more than 6% argon and a few percent methane. Interestingly, there are also trace amounts of at least a dozen other organic compounds (i.e. ethane, hydrogen cyanide, carbon dioxide). The organics are formed as methane, which dominates in Titan's upper atmosphere, is destroyed by sunlight. The result is similar to the smog found over large cities, but much thicker. In many ways, this is similar to the conditions on Earth early in its history when life was first getting started.

• Titan has no magnetic field and sometimes orbits outside Saturn's magnetosphere. It is therefore directly exposed to the solar wind. This may ionize and carry away some molecules from the top of the atmosphere.

• At the surface, Titan's temperature is about 94 K (-290 F). At this temperature water ice does not sublimate and the water at the surface cannot participate in the chemistry of the atmosphere. Nevertheless, there appears to be a lot of chemistry going on; the end result seems to be a lot like a very thick smog.

• There are probably two layers of clouds at about 200 and 300 km above the surface. Other more complex chemicals in small quantities must be responsible for the orange color as seen from space.

• It seems likely that the ethane clouds would produce a rain of liquid ethane onto the surface perhaps producing an "ocean" of ethane (or an ethane/methane mixture) up to 1000 meters deep. Recent ground-based radar observations have cast this into doubt, however.

• Recent observations with the Hubble Space Telescope show remarkable near infrared views of Titan's surface (picture 1, above). Voyager's camera couldn't see through Titan's atmosphere but in the near infrared the haze becomes more transparent, and HST's pictures suggest that a huge bright "continent" exists on the hemisphere of Titan that faces forward in its orbit. These Hubble results don't prove that liquid "seas" exist, however, only that Titan has large bright and dark regions on its surface. The landing site for the Huygens probe has been chosen in part by examining these images. It will be just "offshore" of the largest "continent" at 18.1 degrees North, 208.7 degrees longitude (picture 9).

• The observations by HST also indicate that Titan's rotation is in fact synchronous like most of Saturn's other moons.

Pictures

1. (above) A view of the "four faces of Titan" 125k gif; 36k jpg

2. Titan color composite from Voyager 2 at 4.5 million km 22k jpg

3. looking back at Titan 29k gif; 41k gif; 6k jpg

4. Titan, moon of Saturn, showing cloud bands 159k gif

5. B&W HST image centered at longitude 315 11k gif

6. another B&W HST image 12k gif

7. Mercator projection of Titan 154k gif

8. Titan in visible light from Voyager 104k gif

9. Huygens landing site 22k gif
10. COME-ON+ image (ground-based adaptive optics) 20k gif

    Movies

11. Animation constructed from HST IR pics 116k mpg

More about Titan

• from LANL
• Hubble Space Telescope images of Titan's surface by Mark Lemmon
• HST images of Titan's surface: html, txt

Open Issues

• Are there liquids on the surface?
• Is the interior still hot?
• Why does Titan have a dense atmosphere while the other large moons do not?
• There are a lot of organic compounds and a potentially liquid environment on Titan. It is extremely cold for life, but could it be possible? Titan is one of the best possibilities. In any case, it's interesting as a comparison with the early environment on Earth.
• The Cassini radar mapper and Huygens probe will provide the hard data so frustratingly lacking on this enigmatic moon (if it survives its passage through the US Congress).
